YH2M8432 Umatshini wokuLaphusa uMphezulu oMbini

YH2M8432 Umatshini wokuLaphusa uMphezulu oMbini

Lo matshini ungasetyenziselwa ukupakisha / ukupolisha indawo ephindwe kabini yamacandelo amancinci afana neglasi / i-ceramics / isafire / i-carbon arsenide / ferrite / lithium niobite.

uphando

Abalinganiswa bobugcisa

Iimpawu zobugcisa:
● I-axis nganye yalo matshini yetreyi, ipleyiti esezantsi, ipleyiti engaphezulu ithwala ubunzima nge-TRB (i-tapered roller bear) kunye ne-DGRB (ibhola ye-deep groove), ukuchaneka komatshini kunokuqinisekiswa;
● Iringi yegiya phezulu nasezantsi inokuphunyezwa nge-cam bushing eqhutywa yi-cylinder yomoya;
● Ivili lelanga liqhutywa yi-1.5KW motor enezixhobo zokunciphisa;
● Ipleyiti yokupolisha esezantsi, kunye namakhonkco egiya angaphakathi aqhutywa ngokuthe ngqo ngamagiya okunciphisa, amaza okuguquguquka angena-stepless okulawula isantya, isiqalo esizinzile kunye nokuyeka ngaphandle kwempembelelo.
● Ipleyiti yokupolisha ephezulu iqhutywa ngokuthe ngqo ngegiya enye yokunciphisa, ukuguquguquka okungahambelaniyo kokulawula isantya, ukuqalisa okuzinzileyo & nokuma ngaphandle kwempembelelo, isantya esifanelekileyo sokupholisha sinokufezekiswa ngokucocwa kwezinto ezahlukeneyo.
● Zonke iinxalenye zolawulo zisebenzisa amandla e-24v, anokuqinisekisa ukhuseleko lomsebenzisi kunye nezixhobo.

isicelo
Isixhobo sinokucutshungulwa i-workpiece equka ipleyiti yevalve, ipleyiti yokukhuhlana, ikhonkco eliqinileyo, i-cylinder piston ring, i-oil pump blades, i-silicon, i-germanium, i-quartz crystal, iglasi, i-ceramics, isafire, i-gallium arsenide, i-lithium niobite njl.

ukwenza

Specification

umcimbi	YH2M8432C
Ubungakanani bepleyiti ephezulu(ODIDUkutyeba)	Φ1070×Φ495×45mm
Ubungakanani bepleyiti esezantsi(ODIDUkutyeba)	Φ1070×Φ495×45mm
Uxinzelelo olukhulu lomatshini	300kgf(Iphedi yokupholisha kunye nokupolisha ibrashi)
Iqhekeza lomsebenzi min ubukhulu	0.4mm(Icala elithe tye lomsebenzi)
Isiqwenga somsebenzi max ubukhulu	290mm (Uxande, umgca wediagonal:290mm)
Umsebenzi owenziwe ngomatshini ukuchaneka	I-Output Parallelism inokuqinisekiswa ukufikelela kwi-0.005 xa i-input parallelism ingaphakathi kwe-0.005
Isantya esiphezulu sediski sokusila	Isantya sepleyiti ephezulu: 5-50rpm (ulawulo olungena nyathelo)
Isantya esisezantsi sokusila idiskhi	Isantya sepleyiti esisezantsi: 5-45rpm (ulawulo olungena nyathelo)
Imilinganiselo iyonke (L × W × H)	1600 × 1440 × 2700mm
Lobukhulu seyiyonke (L * W * H)	1600 × 1625 × 2150mm
Isisindo sonke	3200Kg

isiqinisekiso

iziqinisekiso

Iqela lethu leR & D liseka intsebenziswano yexesha elide kunye neYunivesithi yeSizwe yeTekhnoloji yezoKhuselo , iYunivesithi yeTekhnoloji yaseDalian , iYunivesithi yaseHunan , iYunivesithi yaseCentral South , kunye namanye amaziko adumileyo . IYuhuan ikwasisiseko sophando kumfundi ogqirha weYunivesithi yaseHunan, fumana amalungelo awodwa omenzi wechi-5-9 ngonyaka .ufumene amalungelo awodwa omenzi wechiza angama-36.Isatifikethi seemveliso ezisemgangathweni wamazwe ngamazwe ngo-2005ipasile ISO9001: 2000 isiqinisekiso senkqubo yomgangatho wamazwe ngamazwe, imisele imigangatho yemveliso yoshishino.
